Boss DD-3T Digital Delay Pedal

Deskripsi Produk

THE ICONIC DIGITAL DELAY, ENHANCED FOR MODERN PLAYERS

BOSS’s iconic DD-3 Digital Delay has been a pedalboard staple since 1986, loved everywhere for its great sound and simple operation. With the DD-3T, we’ve updated the classic stomp with enhanced functionality while fully retaining the original’s sound and control layout. It’s now possible to tap in delay tempos using the onboard switch or an external one, with your choice of three beat subdivisions. And the direct output jack has been moved next to the main output, providing easier connectivity for wet/dry setups.

FEATURES

Updated version of the industry-standard DD-3, with enhanced functionality for modern players
Ultra-easy operation for fast sound creation
Delay time of 12.5 to 800 ms, divided into three ranges for quick setup
Tap in tempos with the onboard pedal switch or an external footswitch
Short Loop setting for creating phrase loops (same as the Hold function on the original DD-3)
Direct output for sending dry and wet sounds to separate amps
Main and direct output jacks now positioned on one side of the pedal
BOSS five-year warranty

OTHER

Bypass
Buffered bypass

Controls
MODE knob
TIME knob
FEEDBACK knob
E.LEVEL(Effect Level) knob
Pedal switch

Indicator
CHECK indicator (Used for indication of check battery)

Connectors
INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
DIRECT OUT jack: 1/4-inch phone type
TEMPO jack: 1/4-inch phone type
DC IN jack

Power Supply
Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately)

Current Draw
70 mA

Expected battery life under continuous use
Alkaline: Approx. 5 hours
*These figures will vary depending on the actual conditions of use.

Accessories
Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)
Alkaline battery (9 V, 6LR61)

Options (sold separately)
AC adaptor: PSA series
Footswitch: FS-5U, FS-6, FS-7
