•  Six balanced line inputs, for connecting synths or other line-level audio, and four balanced outputs, for monitoring and effects sends
•  Two of the best performing Scarlett mic preamps the range has ever heard – now with Air – for recording vocals

•  Two high headroom instrument inputs, for plugging your guitar or bass straight in
•  Loopback, for grabbing a stereo feed of any combination of hardware inputs and software playback, no cables needed, for simple sampling, streaming or podcasting

SUPPORTED SAMPLE RATES

44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

MICROPHONE INPUTS

Frequency Response 20Hz – 20kHz ± 0.1dB Dynamic Range 111dB (A-weighted) THD N <0.0012% Noise EIN -128dBu (A-weighted) Maximum Input Level 9dBu (at minimum gain) Gain Range 56dB Impedance 3kΩ

LINE INPUTS 1-2 (VARIABLE GAIN)

Frequency Response 20Hz – 20kHz ± 0.1dB Dynamic Range 110.5dB (A-weighted) THD N <0.002% Maximum Input Level 22dBu (at minimum gain) Gain Range 56dB Impedance 60kΩ

LINE INPUTS 3-6 (FIXED GAIN)

Frequency Response 20Hz – 20kHz ± 0.1dB Dynamic Range 110.5dB (A-weighted) THD N <0.002% Maximum Input Level 18dBu (at minimum gain) Impedance 44kΩ

INSTRUMENT INPUTS

Frequency Response 20Hz – 20kHz ± 0.1dB Dynamic Range 110dB (A-weighted) THD N <0.03% Maximum Input Level 12.5dBu (at minimum gain) Gain Range 56dB Impedance 1.5MΩ

LINE/MONITOR OUTPUTS

Dynamic Range (Line Outputs) 108dB THD N <0.002% Maximum Output Level (0 dBFS) 15.5dBu Impedance 430Ω

HEADPHONE OUTPUTS

Dynamic Range 104dB (A-weighted) THD N <0.002% Maximum Output Level 7dBu Impedance <1Ω Compatibility Windows and Mac
